Sina Ekato
1 / 3
| Technical Specifications | |
| Power source | 200V/50HZ |
| Mini permissible stirring volume | 200ml |
| Mini permissible Emulsifying volume | 600ml |
| Maxi permissible Emulsifying volume | 1000ml |
| Maxi working temperature | 120℃ |
| Can reach vacuum | -0.097MPa |
| Maximum treatment viscosity | 100,000cP |
| Stirring motor power | 150W |
| Stirring speed range | 0-200rpm |
| Stirring speed display | Digital display |
| Stirring paddle configuration | Anchor Helical Ribbon Wall scraping mixing paddle |
| Scraper material | PTFE |
| Homogeneous disperse motor power | 1300W |
| Homogeneous disperse speed range | 4000-26000rpm (optional 10000-30000rpm) |
| Homogeneous disperse speed display | LCD display |
| Homogeneous disperse timer | Included |
| Homogeneous working head configuration | 25DG |
| Reaction cover opening | Homogeneous machine hole + material bucket hole + temperature measuring hole + vacuum hole + 3 pcs functional hole |
| Discharge method | Bottom discharge and flip pour discharge |
| Lift support | 350 |
| Contact materials | SIC, SS316L, borosilicate glass, FKM, and PTFE |
| Vacuum hole diameter | 10 |
| Glass Reaction jacket inlet / outlet diameter | 12 |
| Allowable ambient temperature | 5-40℃ |
| Allowable relative humidity | 80% |
| Overall dimension | 400×600×1200 |
| Standard weight | 35KG |
| Packing | Wooden case |
Supported by a professional design center and national light industry research institutes, our engineering team serves as the technological core. We are a professional manufacturer of various types of cosmetic machinery and equipment, serving nationally and internationally famous enterprises across cosmetics, medicine, food, chemical, and electronics industries.
YT-10P-5M Lipstick Freeing Tunnel
SME-65L Lipstick Machine
Lipstick Filling Machine
1. Electric Lift: 300mm stroke, 220V, one-key operation with high precision trapezoidal screw.
2. Mixing System: 150W large torque motor, 0-200rpm digital display, anchor ribbon impeller with PTFE wall scraping.
3. Dispersed Shear System: 1300W brushless motor, 8000-30000rpm range, SS316L working head with SKF bearings.
4. Reactor System: 1L Glass reactor with jacket, SS316L cover, vacuum capability up to -0.09Mpa.
5. Control & Base: Aluminum alloy base with integrated panel operation (Start/Stop/Lift/Stirring).
